IV Flow Regulator

Brief Introduce

I.V. flow regulator is mainly used with other disposable medical instruments, as a human intravenous injection or infusion, blood transfusion to adjust the flow of infusion, accurately control the infusion flow, to prevent the patient’s body cannot bear when the special patients are infused with the special drugs too fast.

Feature

1) With Y injection port (Latex Free) for intermittent medication;

2) Precise flow rate control of IV fluids with range of 5 to 250ml/ hr with tolerance 10% at most;

3) All material support lipid resistant and alcohol resistant. No worry for leaking during use or injection lipid;

4) All connectors meets international 6:100. No worry for compatible problem;

5) Elastic PVC, easy use and no kink.

Warnings

1. Do not use the Infusion set if the device package is damaged.

2. Dispose the device after use. The device is meant for one-time use only.

3. The storage areas need to be well ventilated and free from corrosive gases.

4. It should be well equipped with fire and rat's prevention, moisture and pest control facilities.

5. Do not use if it is over its expiration date.

Application Methods

Step1: Open the pouch package and check the I.V. flow regulator;

Step2: Connect the regulator with the infusion sets;

Step3: Performed by the professional staff, insert the spike fully into the I.V. container and exhaust air bubbles from the set;

Step4: Open the I.V. flow regulator and perform vein puncture, adjust it to the required flow rate.
