Hypodermic needle
Brief Introduce
The hypodermic needle is a single-use, sterile medical device, used for subcutaneous injections. It can be assembled with both luer slip and luer lock syringes.
Feature
1) Needle bevel enables smooth, virtually painless injections;
2) Neat look and attractive design;
3) Translucent needle hub designed for easy selection of desired gauge and safe injection;
4) Internationally accepted color-code;
5) Manufacturing using automated polishing and lubrication processes;
6) Strict quality control procedures ensure consistent performance;
7) Sterilized by EO gas, non-toxic and non-pyrogenic.
Warnings
1. Do not use the needle if the device package is damaged.
2. Dispose the device after use. The device is meant for one-time use only.
3. The storage areas need to be well ventilated and free from corrosive gases.
4. It should be well equipped with fire and rat's prevention, moisture and pest control facilities.
5. Do not use if it is over its expiration date.
Needle Gauge Size
Size | Color Code | Regular Needle Length | ||||||
O. D. (mm) | Gauge | 12mm | 16mm | 19mm | 25mm | 32mm | 38mm | |
1/2" | 5/8" | 3/4" | 1" | 1 ¼" | 1 ½" | |||
0.3 | 30G | Yellow | √ | |||||
0.33 | 29G | Red | √ | |||||
0.36 | 28G | Blue-green | √ | |||||
0.4 | 27G | Grey | √ | |||||
0.45 | 26G | Brown | √ | |||||
0.5 | 25G | Orange | √ | √ | √ | |||
0.55 | 24G | Purple | √ | √ | ||||
0.6 | 23G | Blue | √ | √ | √ | |||
0.7 | 22G | Black | √ | √ | √ | |||
0.8 | 21G | Green | √ | √ | √ | |||
0.9 | 20G | Yellow | √ | |||||
1.1 | 19G | Creamy | √ | |||||
1.2 | 18G | Pink | √ | √ | ||||
1.6 | 16G | White | √ | √ | ||||
1.8 | 15G | Dark blue | √ |
